■目的 Arista-SWでVRFの設定をしてみる。
基本的にCiscoと同じ設定なので備忘録として記載する。
■内容以下コマンドでVRF設定が可能
①まずはvrfの定義をする
vrf definition vrf1
rd 65000:1
vrf definition vrf2
rd 65000:2
②インターフェースVLANにVRFの指定をする
interface Vlan301
vrf forwarding vrf1
ip address 30.0.1.254/24
interface Vlan401
vrf forwarding vrf2
ip address 40.0.1.254/24
③VRF指定でルーティングを記載する
ip route vrf vrf1 40.0.1.0/24 30.0.2.1
ip route vrf vrf2 30.0.1.0/24 40.0.12.1
④IProutingでvrfの指定をする
ip routing
ip routing vrf vrf1
ip routing vrf vrf2
①Arista#sh vrf
Vrf RD Protocols State Interfaces
---------- ------------- --------------- ------------- -------------------
vrf1 65000:1 ipv4 routing Vlan301, Vlan302,
Vlan303, Vlan304,
Vlan305,
vrf2 65000:2 ipv4 routing Vlan401, Vlan402,
Vlan403, Vlan404,
Vlan405,
test-arista#sh ip route vrf vrf1
Codes: C - connected, S - static, K - kernel,
O - OSPF, IA - OSPF inter area, E1 - OSPF external type 1,
E2 - OSPF external type 2, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type2, B I - iBGP, B E - eBGP,
R - RIP, I - ISIS, A B - BGP Aggregate, A O - OSPF Summary
Gateway of last resort is not set
C 30.0.1.0/24 is directly connected, Vlan301
C 30.0.2.0/24 is directly connected, Vlan302
C 30.0.3.0/24 is directly connected, Vlan303
C 30.0.4.0/24 is directly connected, Vlan304
C 30.0.5.0/24 is directly connected, Vlan305
S 40.0.11.0/24 [1/0] via 30.0.12.1, Vlan312
S 40.0.21.0/24 [1/0] via 192.168.207.250, Vlan2007
test-arista#sh ip route vrf vrf2
Codes: C - connected, S - static, K - kernel,
O - OSPF, IA - OSPF inter area, E1 - OSPF external type 1,
E2 - OSPF external type 2, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type2, B I - iBGP, B E - eBGP,
R - RIP, I - ISIS, A B - BGP Aggregate, A O - OSPF Summary
Gateway of last resort is not set
S 30.0.1.0/24 [1/0] via 40.0.12.1, Vlan412
S 30.0.11.0/24 [1/0] via 40.0.12.1, Vlan412
S 30.0.21.0/24 [1/0] via 192.168.203.250, Vlan2003
C 40.0.1.0/24 is directly connected, Vlan401
C 40.0.2.0/24 is directly connected, Vlan402
C 40.0.3.0/24 is directly connected, Vlan403
C 40.0.4.0/24 is directly connected, Vlan404
C 40.0.5.0/24 is directly connected, Vlan405
test-arista#ping vrf vrf2 192.168.204.1
PING 192.168.204.1 (192.168.204.1) 72(100) bytes of data.
^C
--- 192.168.204.1 ping statistics ---
1 packets transmitted, 0 received, 100% packet loss, time 0ms
test-arista#ping vrf vrf2 192.168.204.254
PING 192.168.204.254 (192.168.204.254) 72(100) bytes of data.
80 bytes from 192.168.204.254: icmp_req=1 ttl=64 time=0.065 ms
80 bytes from 192.168.204.254: icmp_req=2 ttl=64 time=0.016 ms
80 bytes from 192.168.204.254: icmp_req=3 ttl=64 time=0.014 ms
80 bytes from 192.168.204.254: icmp_req=4 ttl=64 time=0.017 ms
80 bytes from 192.168.204.254: icmp_req=5 ttl=64 time=0.012 ms
--- 192.168.204.254 ping statistics ---
5 packets transmitted, 5 received, 0% packet loss, time 0ms
rtt min/avg/max/mdev = 0.012/0.024/0.065/0.021 ms, ipg/ewma 0.056/0.044 ms
test-arista#
